Semi-finished coils
Products | Alloy | Temper | Gauge(mm) | Width(mm) | Coil ID(mm) | Coil OD(mm) | Application |
As cast coils | 1050/1060/1070/ 11003003/3005/ 3102/31058006/ 8011/8079 | F(or add one cold pass) H14(One cold pass) H16(One cold pass) | 3.5-6.0 | 800-1800 | 605 505 | Up to 2000 | Re-roll Can be used for normal construction,decoration,electronics applications |
Hot rolled coils | 1*** 3*** 5*** 8*** | F H14(One cold pass) H16(One cold pass) | 3.5-8.0 | 1200-2150 | 605 505 | Up to 2000 | Re-roll Can be used for high end manufacturering/Construction/Decoration/Electronics applications |
Foilstock
Products | Alloy | Temper | Gauge(mm) | Width(mm) | Coil ID(mm) | Coil OD(mm) | Application |
Foilstock for light-gauge Foil | 1235 8079 | H14 H16 | 0.21-0.55 | 1200-2100 | 405 505 | Up to 2000 | Re-roll to light gauge foil,minimum thickness can reach 0.0055 |
Foilstock for household foil/thick-gauge Foil | 1200 1235 8006 8011 8079 | H14 H16 | 0.21-0.35 | 1200-2100 | 405 505 | Up to 2000 | Re-roll to household foil or other foil material |
Foilstock for finstock material | 1200 3102 8011 | H14 H16 | 0.21-0.35 | 600-1800 | 405 505 | Up to 2000 | Re-rolled to finstock |
Common Alloy
Alloy | Temper | Gauge(mm) | Width(mm) | Tension Leveled(mm) | Coil ID(mm) | Application |
1*** 3*** 5*** 8*** | F O H14 H16 H18 H22 H24 H26 | 0.2-10.0 | 50-2150 | Thickness:0.15-1.5Width:920-2130 | 405 505 605 | Construction Decoration Transporatation ... |
Specialty Coil
Alloy | Temper | Gauge(mm) | Width(mm) | Tension Leveled(mm) | Special Features | Coil ID(mm) | Application |
3005 3105 | H24 H26 | 0.21-0.68 | 1200-2100 | Yes | High flatness High surface quality | 405 505 605 | Compositie PanelRoofingConstructionVans... |
5052 | Hx2 Hx4 Hx6 | 0.5-1.5m | 1200-2130 | Yes | High flatness | 405 505 605 | ConstructionBoat buildingMouldingMachinery... |
General sheet
Alloy | Temper | Gauge(mm) | Width(mm) | Length | Tension Leveled(mm) | Application |
1*** 3*** 5*** 8*** | F O H14 H16 H18 H22 H24 H26 H32 H34 | 0.2-10.0 | 50-2150 | Up to 6000 | Thickness:0.15-1.5 Width:920-2130 | Construction Decoration Transporatation ... |
Thick plate
Alloy | Temper | Gauge(mm) | Width(mm) | Length | Application |
2*** | T351 T451 | Up to 200 | 1000-2500 | 2000-10000 | Aviation industry |
6*** | T651 | Defense industry Automobile industry ... | |||
7*** | T651 | Aviation industry Moulding Robot Shell ... |
